SCHNEIDER ZBE102 single contact block for head 22 1NC silver alloy screw clamp terminal

Now: AED 8.00 (Inclusive of VAT)

Qty:

Note: Image for illustrative purpose only, original product will be delivered as per your order specification on the item description, please refer technical data sheet for more information about the product.

IP RATING : IP20
MOUNTING : FRONT MOUNTING
COLOR : SILVER
CONTACT : NC
HS Code :
Lead Time : 3-4 WEEKS
Product or component type - Contact block Sale per indivisible quantity - 5 Connections - terminals - Screw clamp terminals :
<= 2 x 1.5 mm² with cable end conforming to EN 60947-1 Screw clamp terminals :
>= 1 x 0.22 mm² without cable end conforming- to EN 60947-1 [Ith] conventional free air thermal current - 10 A conforming to EN/IEC 60947-5-1 :
VIEW MORE PRODUCT DETAILS

1 year warranty
100% Guaranteed Warranty

Download Product Catalogue

Free Shipping Across UAE
When you spend above 699 AED

100% Genuine Products
Sourced from Trusted Independent Suppliers

Related Products


Main
range of productHarmony XB4
Harmony XB5
product or component typeContact block
device short nameZBE
sale per indivisible quantity5
IP degree of protectionIP20 conforming to IEC 60529
contact operationSlow-break
contact block typeSingle
contacts usageStandard contacts
connections - terminalsScrew clamp terminals, <= 2 x 1.5 mm² with cable end conforming to EN 60947-1
Screw clamp terminals, >= 1 x 0.22 mm² without cable end conforming to EN 60947-1
Complementary
net weight0.011 kg
contacts type and composition1 NC
positive openingWith conforming to EN/IEC 60947-5-1 appendix K
operating travel1.5 mm (NC changing electrical state)
4.3 mm (total travel)
operating force2 N NC changing electrical state
mechanical durability10000000 cycles
tightening torque0.8…1.2 N.m conforming to EN 60947-1
shape of screw headCross compatible with pozidriv No 1 screwdriver
Slotted compatible with flat Ø 4 mm screwdriver
Slotted compatible with flat Ø 5.5 mm screwdriver
contacts materialSilver alloy (Ag/Ni)
short-circuit protection10 A cartridge fuse type gG conforming to EN/IEC 60947-5-1
[Ith] conventional free air thermal current10 A conforming to EN/IEC 60947-5-1
[Ui] rated insulation voltage600 V (pollution degree 3) conforming to EN 60947-1
[Uimp] rated impulse withstand voltage6 kV conforming to EN 60947-1
[Ie] rated operational current3 A at 240 V, AC-15, A600 conforming to EN/IEC 60947-5-1
6 A at 120 V, AC-15, A600 conforming to EN/IEC 60947-5-1
0.1 A at 600 V, DC-13, Q600 conforming to EN/IEC 60947-5-1
0.27 A at 250 V, DC-13, Q600 conforming to EN/IEC 60947-5-1
0.55 A at 125 V, DC-13, Q600 conforming to EN/IEC 60947-5-1
1.2 A at 600 V, AC-15, A600 conforming to EN/IEC 60947-5-1
electrical durability1000000 cycles, AC-15, 2 A at 230 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, AC-15, 3 A at 120 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, AC-15, 4 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, DC-13, 0.2 A at 110 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
1000000 cycles, DC-13, 0.5 A at 24 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to EN/IEC 60947-5-1 appendix C
mounting of blockFront mounting
electrical composition codeC1 (quantity <= 9)
C2 (quantity <= 7)
C3 (quantity <= 6)
C4 (quantity <= 4)
C5 (quantity <= 5)
C6 (quantity <= 3)
C7 (quantity <= 4)
C8 (quantity <= 2)
C9 (quantity <= 3)
C12 (quantity <= 6)
M1 (quantity <= 6)
M2 (quantity <= 4)
M3 (quantity <= 4)
M5 (quantity <= 2)
M6 (quantity <= 2)
M7 (quantity <= 6)
M8 (quantity <= 4)
M9 (quantity <= 2)
SF1 (quantity <= 3)
SF2 (quantity <= 2)
MF1 (quantity <= 2)
MF2 (quantity <= 2)
C10 (quantity <= 2)
M4 (quantity <= 2)
C13 (quantity <= 1)
device presentationBasic element
Environment
protective treatmentTH
ambient air temperature for storage-40…70 °C
ambient air temperature for operation-40…70 °C
standardsEN/IEC 60947-5-1
CSA C22.2 No 14
JIS C8201-5-1
EN/IEC 60947-1
UL 508
EN/IEC 60947-5-4
JIS C8201-1
product certificationsCSA
GOST
BV
DNV
GL
LROS (Lloyds register of shipping)
CCC
UL
vibration resistance5 gn (f= 2…500 Hz) conforming to IEC 60068-2-6
shock resistance30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27
50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27
Packing Units
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Weight10.0 g
Package 1 Height5.5 cm
Package 1 width3.4 cm
Package 1 Length5.4 cm
Unit Type of Package 2BB1
Number of Units in Package 25
Package 2 Weight52.0 g
Package 2 Height5.6 cm
Package 2 width4.3 cm
Package 2 Length5.4 cm
Unit Type of Package 3P06
Number of Units in Package 36400
Package 3 Weight81.276 kg
Package 3 Height77.0 cm
Package 3 width80.0 cm
Package 3 Length60.0 cm

Contractual warranty
Warranty18 months

Specifications

BrandSCHNEIDER ELECTRIC
Model NumberZBE102
IP RATING IP20
MOUNTING FRONT MOUNTING
COLOR SILVER
CONTACT NC
Lead Time 3-4 WEEKS
Product or component type - Contact block Sale per indivisible quantity - 5 Connections - terminals - Screw clamp terminals
<= 2 x 1.5 mm² with cable end conforming to EN 60947-1 Screw clamp terminals
>= 1 x 0.22 mm² without cable end conforming- to EN 60947-1 [Ith] conventional free air thermal current - 10 A conforming to EN/IEC 60947-5-1
Warranty 1 year warranty
